Bus Bar Enclosures
A protective case for busbars up to 4,000 A: a large 300 × 200 section in 3 mm sheet. Aluminium or copper bars are fitted by the busbar maker; the enclosure only carries and protects them.
Specification
| Section | 25 / 100 / 300 / 100 / 25 mm legs, t 3 mm, length 2,500 mm |
|---|---|
| Material | CRCA cold-rolled sheet |
| Finish | Zinc-phosphate + polyester powder RAL 7035, 60-80 µm, all internal faces coated |
| Pattern | Plain (no perforation) |
| Product code | 2.40 |
Reference design, made to order. Size, material, finish and fittings follow your drawing. Protection ratings and loads are design targets, confirmed by test on the first article of each order.
